iX-2224A (Gen 4) – 2U Dual Intel Xeon Scalable Processors
Key Applications
- HPC
- AI Applications
- Corporate- WINS, DNS, Print, Login
- Gateway, provisioning servers
- Network Appliance
- Cloud Computing
Outstanding Features
- 32 DIMM Slots – Up to 4 TB total memory
- 24 x 2.5” Hot-Swap NVMe/SATA/SAS Drive Bays
- 4 x PCI-E 5.0 x16 Slots
- 1 x PCI-E 5.0 OCP Slot
- 2 x M.2 Slots
Specs
| Motherboard | |
|---|---|
| Processor Support | Dual Intel® Xeon® LGA 4677 Scalable Gen4 Processors (Sapphire Rapids) |
| Chipset | Intel® C741 Chipset |
| System Memory (Max.) | Up to 4 TB Registered ECC DDR5 4800MHz SDRAM; 32 DIMM Slots |
| Networking | Dual 10GbE X710-AT2 |
| PCIe Networking Options | Optional 10GbE, 25GbE, 40GbE, 100GbE Ports Available |
| VGA/BMC | ASPEED AST2600 BMC |
| Remote Management | Redfish API, IPMI 2.0; KVM with Dedicated LAN |
| Chassis | |
|---|---|
| Form Factor | 2U Rackmount |
| Dimensions(mm) | 840mm x 447mm x 88mm |
| Storage | |
|---|---|
| Onboard Storage Controller | Intel® SATA (6 Gbps) Controller + NVMe Controller |
| RAID Controller Options | Optional Hardware RAID or SAS HBA Available |
| Drive Bays | 24 x 2.5” Hot-Swap |
| Expandability | |
|---|---|
| Expansion Slots | 2 x PCI-E 5.0 x8 or 1 x PCI-E 5.0 x16 FHFL or FHHL 1 x PCI-E 5.0 x16 LP 1 x PCI-E 5.0 x16 OCP |
| Power | |
|---|---|
| Power Supply | 2 x 1600W Redundant High-Efficiency Power Supplies with I2C & PMBus |
I/O Layout
